Bellon front-mounted disc mowers
High-precision cutting and superior operating speed
Precision and dynamic adaptation: the Bellon front-mounted disc mower range ensures ash-free, high-purity forage and rapid, uniform sward regrowth, driven by the advanced engineering of the cutter bar.
Our mowers at a glance
The DF and DFH series combine high-speed disc mowing with the operational advantages of front-mount installation, maximizing productivity and optimizing cutting cycles across all forage crops.
Maximum working width of the series
Discs equipped with high-strength blades for a clean cut
Low power requirement, ideal for compact tractors
Maximum versatility with dual-speed PTO engagement
Performance and precision: peak efficiency in front-mounted disc mowers
The DF and DFH series represent the cutting edge of front-mounted mowing. The disc bar allows operation at higher speeds compared to traditional systems, while ensuring superior cut quality that preserves the nutritional properties of the forage. The innovative hydraulic system with a nitrogen accumulator (DFH Series) allows for preloading the distribution system to ensure constant and controlled ground pressure, reducing friction and the resulting fuel consumption. It is the preferred choice for those seeking a final product free of impurities and a machine capable of adapting to any ground irregularities.
Safe and easy to maneuver
Thanks to their compact design, they are suitable for medium-horsepower tractors without compromising the vehicle’s stability
Bellon disc technology
The high-performance discs deliver fast working speeds and minimized maintenance, maximizing field uptime season after season.
Optional conditioner
The mowers can be equipped with chevron rubber rollers (GM Series) to accelerate crop drying cycles while fully preserving the forage’s nutritional value.
DF series
Spring-Suspended Mowers
| DF4000 - DF4003 | DF5000 - DF5000GM | DF6000 - DF6000GM | DF6003 - DF6003GM | |
|---|---|---|---|---|
| Cutting width | 1,67m | 2,05m | 2,40m | 2,40m |
| Discs | 4 | 5 | 6 | 6 |
| Blades | 8/12 | 10 | 12 | 18 |
| Cardan shaft | 1 | 1 | 1 | 1 |
| Power absorbed | 30HP | 40HP | 50HP | 50HP |
| PTO revolutions | 540-1000rpm | 540-1000rpm | 540-1000rpm | 540-1000rpm |
| Mower’s weight | 300kg | 470kg | 520kg | 520kg |
| Conditioner’s weight | - | 100kg | 130kg | 130kg |
DFH series
Nitrogen-Suspended Mowers
| DFH6000 - DFH6000GM | DFH6003 - DFH6003GM | DFH7000 - DFH7000GM | DFH8000 - DFH8000GM | DFH8003 - DFH8003GM | |
|---|---|---|---|---|---|
| Cutting width | 2,40m | 2,40m | 2,80m | 3,20m | 3,20m |
| Discs | 6 | 6 | 7 | 8 | 8 |
| Blades | 12 | 18 | 14 | 16 | 24 |
| Cardan shaft | 1 | 1 | 1 | 1 | 1 |
| Power absorbed | 70HP | 70HP | 80HP | 100HP | 100HP |
| PTO revolutions | 540-1000rpm | 540-1000rpm | 1000rpm | 1000rpm | 1000rpm |
| Mower’s weight | 700kg | 700kg | 806kg | 920kg | 920kg |
| Conditioner’s weight | 135kg | 135kg | 140kg | 150kg | 150kg |
